Vibrating feeder

Strong points Vibrating feeder

Reliable and tough

Designed for extreme applications with hard, abrasive rock.

Enhancedstability

Rubber suspensions or metal springs
Off-side stabilizers.

Maximizedsize sorting

Independent scalping bars with adjustable spacing.

Yield: 100-500 t/h

Maximum output for feeding the coarse rock grinding station.

Features Vibrating feeder

Roc Impact (ROC) vibrating grizzly feeders are designed mainly for fixed primary crushing plants. They regulate the feed rate to the crusher while separating materials by size.

The vibration unit is run by two vibrators located underneath, or with a motor-driven eccentric driveshaft.

They create a linear vibrating motion with an incline of 45° to the horizontal frame of the feeder (depending on the installation).

A wear-resistant electrode extends the life of the feeder.
The design of the rods allows them to spread make it easier to remove blockages and to maximize size-based sorting.
Four sets of springs or rubber mounts support the feeder to better stabilize it during operation.
Feed rate can be controlled remotely thanks to the variable speed motor.

Technical specifications

Type	Power (Hp)	Length x width (Inch)	Production (Stph)	Weight (Lbs)
ROC V 6.12	2 x 1.5	26 x 47	110	970
ROC V 6.20	2 x 1.5	26 x 79	165	1323
ROC V 8.12	2 x 2.6	31 x 47	275	1598
ROC V 8.20	2 x 2.6	31 x 79	330	1763
ROC V 12.20	2 x 3	47 x 79	385	2039
ROC V 15.15	2 x 3	59 x 59	551	3648

Type	Power (Kw)	Length x width (mm)	Production (T/h)	Weight (Kg)
ROC V 6.12	2 x 1,1	650 x 1200	100	440
ROC V 6.20	2 x 1,1	650 x 2000	150	600
ROC V 8.12	2 x 1,9	800 x 1200	250	725
ROC V 8.20	2 x 1,9	800 x 2000	300	800
ROC V 12.20	2 x 2.2	1200 x 2000	350	925
ROC V 15.15	2 x 2,2	1500 x 1500	500	1655

Download the detailed product brochure Vibrating feeder
